Degree Electrical Engineering : Laboratory

Sr No Name of Laboratory LaboratoryIn Charge Lab Assistant Area Sq.M Total Investment
1 AC Machines Lab Prof. L. S. Patil Mr. D. B. Phalake 66 Rs. 8,41,834/-
2 DC Machines Lab Mr. D. S. Patil Mr. D. B. Phalake 66 Rs. 5,00,000/-
3 Control Systems Lab Mr. S. M. Patil Mr. V. R. Phalake 66 Rs 9,27,860/-
4 Power Systems Lab Miss. T. S. Bandgar Mr. J. B. Patil 66 Rs 8,36,190/-
5 Switchgear Protection Lab Mr. R. D. Patil Mr. V. R. Phalake 66 Rs 13,72,000/-
6 Electrical Drives Lab Mr. S. Y. Gadgune Mr. J. B. Patil 66 Rs 8,53,000/-
7 Machine Design Lab Mr. S. N. Sawant Mr. J. B. Patil 66 Rs 11,80,515/-
8 Basic Electrical Lab Mr. A. V. Datar Mr. D. B. Phalake 66 Rs. 1,00,000/-
9 P. G. Lab Mr. R. R. Todkar Mr. V. R. Phalake 66 Rs 8,36,190/-



1.

Name of Laboratory AC Machines Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Prof. L. S. Patil

4.

Laboratory Assistant Mr. D. B. Phalke

5.

Laboratory Investment Rs. 8,41,834/-

6.

Laboratory Resources

List of Major Equipment

1. 3 ph SC induction motor& DC shunt generator load test
2. 3 ph synchronous motor & DC shunt generator
3. 3 ph slip ring IM & DC shunt generator
4. 3ph 2 KVA isolation transformer
5. 3 ph 20A dimmer
6. 3 ph motor with break load
7. 3 ph IM coupled with generator
8. 3 ph alternator coupled to 3 ph SCIM



1.

Name of Laboratory DC Machines Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Prof. D. S. Patil

4.

Laboratory Assistant Mr. D. B. Phalke

5.

Laboratory Investment Rs. 5,00,000/-

6.

Laboratory Resources

List of Major Equipment

1. 15 kw DC power supply rectifier unit (Static)
2. 14 kw DC power supply rectifier unit (Dynamic)
3. DC motor & generator set
4. DC motor & alternator set
5. DC motor & DC shunt generator
6. DC motor & DC compound generator
7. DC shunt motor with break load test
8. DC generator coupled to induction motor



1.

Name of Laboratory Control Systems Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Mr. S. M. Patil

4.

Laboratory Assistant Mr. V. R. Phalake

5.

Laboratory Investment Rs 9,27,860/-

6.

Laboratory Resources

List of Major Equipment

1. Lenovo Think Centre Desktop, PC-i5, 4 gb RAM. HDD 1 TB, Lenovo Colour Monitor, Champion UPS
2. 2 gb graphics card
3. HP Lasejet Printer M1005



1.

Name of Laboratory Power Systems Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Miss. T. S. Bandgar

4.

Laboratory Assistant Mr. J. B. Patil

5.

Laboratory Investment Rs 8,36,190/-

6.

Laboratory Resources

List of Major Equipment

1. Lenovo Think Centre Desktop, PC-i5, 4 gb RAM. HDD 1 TB, Lenovo Colour Monitor, Champion UPS
2. 2 gb graphics card
3. HP Lasejet Printer M1005



1.

Name of Laboratory Switchgear Protection Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Mr. R. D. Patil

4.

Laboratory Assistant Mr. V. R. Phalake

5.

Laboratory Investment Rs 13,72,000/-

List of Major Equipment

1. ElectroMechanical type Phase Fault Relays Kit with source Unit
2. ElectroMechanical type Earth Fault Relays Kit with source Unit
3. ElectroMechanical type Over Voltage Relays Kit with source Unit
4. ElectroMechanical type Over Current Relay Kit with source Unit
5. Electromechanical Type Directional Over Current Relay Kit with source Unit
6. MicroProcessor based Over Current Relay with Differential Characteristics Kit with source Unit
7. MicroProcessor based E/F included over/under voltage Relay Kit with source Unit
8. MicroProcessor based Impedance Relay Kit with source Unit
9. MicroProcessor based Directional Over Current Relay Kit with source Unit
10. Differential Relay Kit with source Unit
11. Relay Test kit with source Unit



1.

Name of Laboratory Electrical Drives Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Mr. S. Y. Gadgune

4.

Laboratory Assistant Mr. J. B. Patil

5.

Laboratory Investment Rs 8,53,000/-

List of Major Equipment

1. SCR/TRIAC/DIAC/MOSFET/IGBT Char. Kit
2. Single phase Full wave bridge converter feeding DC motor kit
3. Morgans Chopper Kit
4. Three-Phase Induction Motor Control using PWM inverter with V/F scheme
5. DSO_Specification TBS1052B, 50MHz-200MHz
6. Three phase fully controlled converter (with microcontroller based firing,1000W lamp load, 5A capacity, Isolated output)
7. Chopper circuit using power MOSFET for motor control with Motor(With ¼ HP ,110V DC series motor with loading arrangement, spring Balance ,speed indicator)
8. Three phase induction controller using slip power recovery scheme
9. 3 phase induction motor controller using V/F scheme and PWM method for 0.5HP motor Above and below Base Speed
10. Chopper circuit using power MOSFET for motor control with Motor (with microcontroller based firing, ½ HP DC motor ,isolated output)



1.

Name of Laboratory Machine Design Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Mr. S. N. Sawant

4.

Laboratory Assistant Mr. J. B. Patil

5.

Laboratory Investment Rs 11,80,515/-

List of Major Equipment

1. Lenovo Think Centre Desktop, PC-i5, 4 gb RAM. HDD 1 TB, Lenovo Colour Monitor, Champion UPS
2. 2 gb graphics card
3. HP Lasejet Printer M1005
4. Wheastones Bridge, Kelvins Double Bridge
5. Maxwells Bridge kit, Hays Bridge kit
6. Andersons Bridge kit, Schering Bridge Kit
7. Wien Bridge Kit, Dwens Bridge Kit
8. Linear Variable Differential Transducer Kit
9. Reciprocity Therom Chassis, ThevininsTherom Chassis, NortansTherom Chassis
10. Superposition  Therom Chassis, Compensation Therom Chassis, Maximum Power Transfer Theorem Chassis



1.

Name of Laboratory Basic Electrical Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Mr. A. V. Datar

4.

Laboratory Assistant Mr. D. B. Phalake

5.

Laboratory Investment Rs 1,00,000/-

List of Major Equipment

1. Analog DC ammeter (0-2.5A, 0-5A, 0-10A,)
2. Analog DC voltmeter (0-150/250 V)
3. Analog AC wattmeter (5/10A, 300/600V)
4. Lux meter, Digital AC clamp meter
5. Power Factor meter
6. Analog AC voltmeter (300/600V)
7. Analog AC ammeter (5/10/15A)
8. 1 ph 1 kVA Transformer (8/16A)
9. KCL-KVL Verification Kit
10. Staircase and Godown wiring kit



1.

Name of Laboratory P. G. Lab

2.

Area of Laboratory 66 sqm

3.

Laboratory Incharge Mr. R. R. Todkar

4.

Laboratory Assistant Mr. V. R. Phalake

5.

Laboratory Investment Rs 8,36,190/-

List of Major Equipment

1. Lenovo Think Centre Desktop, PC-i5, 4 gb RAM. HDD 1 TB, Lenovo Colour Monitor, Champion UPS
2. 2 gb graphics card
3. HP Lasejet Printer M1005
